CHAPTER 3: INSTA LL ATION
3.1 PACKAGE CONTENTS
Your package contains the following items:
(1) Modular KVM Matrix Switch
(1) power cord per built-in power supply unit
(1) serial control cable
Mounting accessories
Java tool
(1) CATx newtork cable (cross-wired)
(1) Quick Start Guide
If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com.
3.2 SYSTEM SETUP
NOTE: We recommend that first-time users set up the system in the same room as a test setup. This will allow you to identify
and solve any cabling problems, and experiment with your system more conveniently.
MATRIX SETUP
1. Install the CPU and CPU boards.
2. Connect keyboard, mouse and monitor to the CPU board of the matrix.
3. Connect the matrix to the power supply.
4. Open OSD via keyboard command <hotkey>, <o> and log in with administrator rights in the main menu under configuration
(see Section 4.2.1).
5. Configure initially as requested.
NOTE: After you configure the system, we recommend that you save the configuration by selecting Configuration > Save
and restart the matrix by selecting Restart Matrix.
6. Optional: Establish a network connection between the matrix and the Java Tool so you can set an extended configuration
(see Section 4.2.2).
The default IP address is 192.168.100.99 and DHCP is deactivated. When installing several matrices at the same time,
we strongly recommend that you install them in sequence and to assign unique IP addresses in order to avoid IP address
conflicts.
EXTENDER SETUP
1. Connect the CON Units to the matrix by using the interconnect cables (CATx or fiber).
2. Connect the CON Units to the input devices to be used (for example, keyboard and mouse).
3. Connect the 5-VDC power supply units to the CON Units.
4. Check the basic function of the CON Unit by opening the OSD via keyboard command <hotkey>, <o>.
5. Connect the source (computer, CPU) to the CPU Unit of the extender using the provided connection cables.
6. Connect the CPU Unit to the matrix using the interconnect cables (CATx or fiber).
