CHAPTER 4: CONFIGURATION
JAVA TOOL
 Select Definition > EXT Units in the task area.
FIGURE 4-44. DEFINITION—EXT UNITS
To change the Extender OSD settings, proceed as follows:
1. Select the console extender in the EXT Units list for which the Extender OSD settings are to be adjusted.
2. Open the Extender OSD Data tab.
3. Adjust the desired settings and confirm your changes by pressing the Apply button.
4.11.4 FAVORITE LIST CONSOLES
Individual favorite lists of CPUs to be switched frequently can be created for all consoles in this menu. A favorite list can contain
up to 16 different CPUs.
The switching of the favorites is done via hotkey using the keyboard (see Section 5.1.1).
You have the following options to access the menu.
OSD
