CHAPTER 2: OVERVIEW

2.6.4 80-PORT CHASSIS (ACX080)

FIGURE 2-5. 80-PORT CHASSIS, FRONT VIEW

TABLE 2-8. 80-PORT CHASSIS FRONT VIEW COMPONENTS

NUMBER IN FIGURE 2-5 COMPONENT

1 Slot for fan tray 1

2 Slot for power supply unit 1

3 Slot for I/O boards #1–10

4 Slot for power supply unit 2

5 Slot for CPU board

6 Slot for air filter

7 Slot for fan tray 2
