CHAPTER 5: OPERATION
5.12 SUMMARY OF KEYBOARD COMMANDS
The following table contains a summary of keyboard commands that can activate extender and matrix functions after executing
the hotkey.
TABLE 5-7. EXTENDER KEYBOARD COMMANDS
KEYBOARD COMMAND DESCRIPTION
<hotkey>, <a> Download of DDC information for the monitor connected to the CON Unit into the CPU Unit
<hotkey>, <k>, <1>, <Enter> Switch to the KVM connection 1 (only with HDMI CON Units with available connection for a local source)
<hotkey>, <k>, <2>, <Enter>
Switch to the KVM connection 2 (only with HDMI CON Units with available connection for a local source and a
redundant interconnection)
<hotkey>, <|>, <Enter> Switch to local source (computer, CPU) (only with HDMI CON Units with available connection for a local source)
<hotkey>, <h>, <w>, <Enter>
USB-HID Ghosting: Write device descriptions of the input devices connected to the CON Unit into the CPU Unit.
Activate the emulation in the CPU Unit.
<hotkey>, <h>, <e>, <Enter> Activate the emulation of already stored device descriptions in the CPU Unit
<hotkey>, <h>, <d>, <Enter>
Deactivate the emulation of active device descriptions in the CPU Unit. The input devices connected to the CON
Unit will be passed transparently to the source (computer, CPU)
<hotkey>, <h>, <r>, <Enter>
Deactivate the emulation of active device descriptions in the CPU Unit. Delete the descriptions out of the CPU
Unit. The input devices connected to the CON Unit will be passed transparently to the source (computer, CPU)
<hotkey>, <d>, <1>, <Enter> Switch to video channel 1 of the Dual-Head CPU Unit (dual-head series only)
<hotkey>, <d>, <2>, <Enter> Switch to video channel 2 of the Dual-Head CPU Unit (dual-head series only)
TABLE 5-8. MATRIX KEYBOARD COMMANDS
KEYBOARD COMMAND DESCRIPTION
<hotkey>, <o> Open OSD
<hotkey>, <m>, <o> Open OSD of the master matrix in a cascaded environment
<hotkey>, <s>, <o> Open OSD of the sub matrix in a cascaded environment
<hotkey>, <Enter> Set a KVM connection (keyboard, mouse and video) to the selected source (computer, CPU)
<hotkey>, <Space> Set a video only connection to the selected source (computer, CPU)
<hotkey>, <Left-Shift> + <Enter> Set a Private Mode connection to the selected source (computer, CPU)
<hotkey>, <Backspace> Close the current connection of the console
<hotkey>, <p> Switch back to the previous connected source (computer, CPU) with a KVM connection
<hotkey>, <1>…<16>, <Enter>
(<Space> or <Left-Shift> + <Enter>)
Switch to a source (computer, CPU) stored in the Favorite List with a KVM connection (video only
or Private-Mode connection)
<hotkey>, <F1>…<F16> Execute a predefined macro
<hotkey>, <c>, <new hotkey code> <Enter> Change the hotkey according to the predefined hotkey table
<hotkey>, <c>, <0>, <new hotkey key> <Enter> Define freely selectable hotkey
<hotkey>, <f>, <new hotkey key code> <Enter> Change the hotkey for direct OSD access according to the predefined hotkey table
<hotkey>, <f>, <0>, <new hotkey key> <Enter> Define freely selectable hotkey for direct OSD access
<hotkey>, <Num 0> Switch the USB-HID signal to the user’s display (CON Unit with keyboard and mouse)
<hotkey>, <Num 1> Switching of the USB-HID signals to display #1
<hotkey>, <Num 2> Switching of the USB-HID signals to display #2
