CHAPTER 1: SPECIFICATIONS
1.6 DIMENSIONS
TABLE 1-21. DIMENSIONS
PRODUCT CODE SPECIFICATION DIMENSION
ACX576
Matrix 43.75"H x 17.7"W x 17.1"D (110.8 x 45 x 43.5 cm)
Shipping Box 49"H x 25.6"W x 26.8"D (124.5 x 65.1 x 68.1 cm)
ACX576S
Matrix 43.75"H x 17.7"W x 17.1"D (110.8 x 45 x 43.5 cm)
Shipping Box 49"H x 25.6"W x 26.8"D (124.5 x 65.1 x 68.1 cm)
ACX288
Matrix 12"H x 19"W x 22.8"D (33 x 48.3 x 57.8 cm)
Shipping Box 29.9"H x 25.6"W x 26.8"D (76 x 65 x 68 cm)
ACX160
Matrix 12"H x 19"W x 15.8"D (33 x 48.3 x 40 cm)
Shipping Box 21.3"H x 25.6"W x 26.8"D (54 x 65 x 68 cm)
ACX080
Matrix 9.1"H x 19"W x 7"D (23 x 48.3 x 17.8 cm)
Shipping Box 14.2"H x 25.2"W x 22.4"D (36 x 64 x 57 cm)
ACX048
Matrix 9.1"H x 19"W x 5.3"D (23 x 48.3 x 13.3 cm)
Shipping Box 12.4"H x 25.2"W x 22.4"D (31.6 x 64 x 57 cm)
1.7 SHIPPING WEIGHT
TABLE 1-22. SHIPPING WEIGHT
PRODUCT CODE SPECIFICATION WEIGHT
ACX576, ACX576S
Matrix 170 lb. (77.3 kg) fully equipped
Shipping Box 190.6 lb. (86.6 kg)
ACX288
Matrix 76.2 lb. (34.6 kg), fully equipped
Shipping Box 90.6 lb. (41.1 kg)
ACX160
Matrix 60.0 lb. (26.3 kg), fully equipped
Shipping Box 69.9 lb. (31.7 kg)
ACX080
Matrix 24.5 lb. (11.1 kg), fully equipped
Shipping Box 34.4 lb. (15.6 kg)
ACX048
Matrix 19.6 lb. (8.9 kg), fully equipped
Shipping Box 26.7 lb. (12.1 kg)
1.8 MTBF
The following table contains the mean time between failure (MTBF) in power-on hours (POH). The estimate is based on the FIT
rates of the parts included. FIT rates are based on normalized environmental conditions of T = 140° F (60° C) and activation energy
(Ea) of 0.7 eV. Calculations are based on 90% confidence limit.
We estimate that inside the housing, temperature will be 59° F (15°C) higher than the ambient temperature. Therefore, the MTBF
calculation refers to an ambient temperature of 113° F (45° C). The humidity is limited to 60%.
