Canon LASER SHOT LBP3500 User Manual

5-20
Routine Maintenance
5
Adjusting the Printing Position
4 Click [OK].
The Printing Position Adjustment Print is printed as shown in the following. The
printed arrow is the top edge of the Printing Position Adjustment Print.
Next, check the printout results and specify the position to be adjusted in "Adjusting the
Printing Position" (See p. 5-20).
Adjusting the Printing Position
Next, check the printout results of the Printing Position Adjustment Print and specify
the direction and position to be adjusted.
The measurements of printed on paper are as the following:
5 mm
10 mm
5 mm
10 mm
*5 mm from each edge of paper

Canon LASER SHOT LBP3500 Specifications

General

Print Technology	Laser
Print Speed	25 ppm (A4)
Connectivity	USB 2.0
Memory	8 MB
Duplex Printing	Manual
Weight	11.2 kg
Paper Capacity	250 sheets
Media Size	A4, Letter, Legal, Executive
Print Resolution	600 x 600 dpi
