7-7
Tr oubleshooting
7
Paper Jams
Paper Jam Area
The messages displayed in the Printer Status Window indicate where the paper is
jammed, and there are the following kinds.
Paper Jam Area Message
a
Duplex print transport area (only when
the duplex unit is installed)
<Duplex Unit>
b Output tray, Sub-output tray <Sub-output Tray>
c Inside the front cover <Front Cover>
d Multi-purpose tray <Multi-purpose Tray>
e Cassette 1 <Cassette 1>
f
Cassette 2 (only when the paper
feeder is installed)
<Cassette 2>
Output Tray
Multi-purpose Tray
Paper Feeder Unit
(Optional)
Duplex Unit (Optional)
c
d
a
e
f
b
b
Sub-output Tray
Cassette 1
Cassette 2
Paper flow for 1-sided printing
Paper flow for 2-sided printing

Canon LASER SHOT LBP3500 Specifications

General

Print Technology	Laser
Print Speed	25 ppm (A4)
Connectivity	USB 2.0
Memory	8 MB
Duplex Printing	Manual
Weight	11.2 kg
Paper Capacity	250 sheets
Media Size	A4, Letter, Legal, Executive
Print Resolution	600 x 600 dpi
