Loading Paper in a Paper Cassette
2-30
Loading and Outputting Paper
2
● While holding the lock release lever of the rear paper guide, slide the
guide to the size mark for the paper to be loaded.
Align the position of (A) with the size mark for the paper to be loaded.
IMPORTANT
Do not use the "A4R", "LTRR", and "8.5 x 13" position.
3
Load the paper stack so that the rear edge is aligned with the
paper guide.
CAUTION
When loading paper, take care not to cut your hands with the edges of the
paper.
IMPORTANT
•
Be sure to check if the paper guide is at the position of the size of the loaded paper.
If the paper guide is set at a wrong position, this may result in misfeeds.
•
If you use paper that has been poorly cut, multiple sheets of paper may be fed at
once. In this case, fan the paper thoroughly, and then align the edges of the stack
on a hard, flat surface.
Cassette 1 Cassette 2
Cassette 1 Cassette 2
(A)
(A)
To Next Page
