2-26
Loading and Outputting Paper
2
Loading Paper in a Paper Cassette
Loading Paper in a Paper Cassette
The paper cassette can be loaded with up to approximately 250 sheets of plain
paper (64 g/m
2
) at sizes of A3, B4, A4, B5, A5, Ledger (11 x 17), Legal, Letter,
Executive, 16K and plain paper of the following custom paper sizes.
•
When loading paper in portrait orientation: Width 210.0 to 297.0 mm; Length
210.0 to 431.8 mm*
*When loading paper that is 279.5 to 297.0 mm wide in Cassette 1, the paper length should be 210.0 to 420.0 mm.
•
When loading paper in landscape orientation: Width 210.0 to 297.0 mm; Length
148.0 to 297.0 mm
When the paper source has run out of paper, a message indicating there is no
paper appears in the Printer Status Window, and the (Load Paper) indicator
(orange) comes on or blinks. In this case, refill paper.
The paper loading methods are different between standard size paper and custom
size paper. Therefore, load paper properly using the following procedures.
•
When Loading Standard Size Paper (See p. 2-27)
•
When Loading Custom Size Paper (See p. 2-34)
IMPORTANT
•
For more details on the usable paper, see "Usable Paper," on p. 2-2.
•
For details on handling the paper cassette, see "Precautions for Handling the
Multi-purpose Tray or Paper Cassette," on p. 2-15.
•
Do not load paper other than plain paper (60 - 90 g/m
2
) in the paper cassette. This may
result in paper jams or damage to the printer.
NOTE
•
Load paper in the optional 250-sheet universal cassette UC-67 in the same manner as
you load paper in Cassette 1.
•
Load paper in the optional 500-sheet universal cassette UC-67K in the same manner as
you load paper in Cassette 2.
To Next Page
