Canon LASER SHOT LBP3500 User Manual

8-16
Appendix
8
Windows Firewall
Configuring Windows Firewall to Unblock Communication
with the Print Server
IMPORTANT
If you do not perform the following settings on the client computers, the printer status may
not be displayed properly in the Printer Status Window, and some of the printer functions
may not operate properly.
1 From the [Start] menu, select [Control Panel].
2 Click [Network and Internet Connections], then click
[Windows Firewall].
3 In the [Exceptions] sheet in the [Windows Firewall] dialog box,
select the [File and Printer Sharing] check box, and then click
[OK].
Windows Firewall is configured to unblock communication with the print server.

Canon LASER SHOT LBP3500 Specifications

General

Print Technology	Laser
Print Speed	25 ppm (A4)
Connectivity	USB 2.0
Memory	8 MB
Duplex Printing	Manual
Weight	11.2 kg
Paper Capacity	250 sheets
Media Size	A4, Letter, Legal, Executive
Print Resolution	600 x 600 dpi
