PurposeCommand or Action
Example:
RP/0/RSP0/CPU0:router(config-ospf)# nsf
cisco enforce global
•
Use the nsf cisco command with the optional enforce and
global keywords if the router is expected to perform NSF
during restart. However, if non-NSF neighbors are detected,
NSF restart is canceled for the entire OSPF process.
Sets the minimum time between NSF restart attempts.
nsf interval seconds
Step 5
Example:
RP/0/RSP0/CPU0:router(config-ospf)# nsf
interval 120
When you use this command, the OSPF process must be
up for at least 90 seconds before OSPF attempts to perform
an NSF restart.
Note
Sets the maximum time allowed for external route learning in
seconds.
nsfflush-delay-timeseconds
Example:
RP/0/RSP0/CPU0:router(config-ospf)#nsf
flush-delay-time 1000
Step 6
Sets the maximum route lifetime of NSF following a restart in
seconds.
nsflifetimeseconds
Example:
RP/0/RSP0/CPU0:router(config-ospf)#nsf
lifetime 90
Step 7
Enables ietf graceful restart.nsfietf
Example:
RP/0/RSP0/CPU0:router(config-ospf)#nsf
ietf
Step 8
commit
Step 9
Configuring OSPF Version 2 for MPLS Traffic Engineering
This task explains how to configure OSPF for MPLS TE. This task is optional.
For a description of the MPLS TE tasks and commands that allow you to configure the router to support
tunnels, configure an MPLS tunnel that OSPF can use, and troubleshoot MPLS TE, see Implementing MPLS
Traffic Engineering on Cisco ASR 9000 Series Router module of the Cisco ASR 9000 Series Aggregation
Services Router MPLS Configuration Guide
Before You Begin
Your network must support the following features before you enable MPLS TE for OSPF on your router:
•
MPLS
•
IP Cisco Express Forwarding (CEF)
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.1.x
OL-30423-03 383
Implementing OSPF
Configuring OSPF Version 2 for MPLS Traffic Engineering
