Cisco ASR 5500 Installation Guide

NotesLED StateLED ColorLabel
Card is offline.OFF
—
Run/Fail
OFF
—
Active
OFF
—
Redundant
Checking Status LEDs on FSCs
The table below identifies the operational and transitional states for LED indicators on an FSC.
Table 18: FSC Operating States and Status LED Indicators
NotesLED StateLED ColorLabel
Card Transition
Card is booting, starting or initializing.BlinkGreen
Run/Fail
OFF
—
Active
OFF
—
Redundant
SSD 1 is idle.OFF
—
Drive 1 Active
SSD 2 is idle.OFF
—
Drive 2 Active
Card Active (Normal)
Redundant switch fabric
Redundant storage
ONGreenRun/Fail
ONGreenActive
ONGreenRedundant
SSD 1 is being accessed.BlinkGreenDrive 1 Active
SSD 2 is being accessed.BlinkGreenDrive 2 Active
Card Active
Non-redundant switch fabric
Non-redundant storage
ONGreenRun/Fail
ONGreenActive
ONAmberRedundant
SSD 1 is being accessed.BlinkGreenDrive 1 Active
SSD 2 is being accessed.BlinkGreenDrive 2 Active
Card Failed
ASR 5500 Installation Guide
93
System Power-up
Checking Status LEDs on FSCs
