the top ejector handle against the front of the card. Tightening the captive Phillips #2 screw within the top

ejector handle secures the subhandle and circuit card to the card cage.

Figure 11: Card Ejector Handle

Ejector subhandle (interlock)2Ejector handle1

Captive screw (Phillips #2)3

Circuit Cards

The installation procedure described below is identical for all circuit cards in the chassis. Circuit cards include:

SSC, FSC, DPC/UDPC, DPC2/UDP2, MIO/UMIO.
