NotesLED StateLED ColorLabel

Card has failed and is offline.ONRedRun/Fail

OFF

—

Active

OFF

—

Redundant

SSD 1 is idle.OFF

—

Drive 1 Active

SSD 2 is idle.OFF

—

Drive 2 Active

Card Offline

Card is offline.OFF

—

Run/Fail

OFF

—

Active

OFF

—

Redundant

SSD 1 is idle.OFF

—

Drive 1 Active

SSD 2 is idle.OFF

—

Drive 2 Active

Checking Status LEDs on SSC

The table below identifies the operational and transitional states for LED indicators on an SSC.

Table 19: SSC Operating States and Status LED Indicators

NotesLED StateLED ColorLabel

Card Transition

Card is booting, starting or initializing.BlinkGreen

Run/Fail

OFF

—

Active

OFF

—

Redundant

Card Active (Normal)

Card is backed up by other SSC.ONGreenRun/Fail

ONGreenActive

ONGreenRedundant

Card Active

Card is not backed up by other SSC.ONGreenRun/Fail

ONGreenActive

ONAmberRedundant

Card Failed
