WeightDepthWidthHeightNotesComponent
15 lbs (6.8 kg)21.5 in. (54.6 cm)8.5in. (21.6 cm)3.5 in. (8.9 cm)
—
Power Filter Unit
6 lbs (2.7 kg)6.75in. (17.1 cm)1.75 in. (4.44cm)19.75 in. (50.2
cm)
—
FSC
4.5 lbs (2 kg)
—
SSC
18 lbs (8.16 kg)19.5 in.
(49.5 cm)
1.75 in.
(4.44 cm)
21.75 in.
(55.24 cm)
6MIO or UMIO
18.5 lbs (8.4 kg)
—
DPC or UDPC
22.7 lbs (10.3 kg)
—
DPC2 or UDPC2
1 lb (0.45 kg)6.25 in. (7 cm)1.75 in. (4.44 cm)19.75 in. (50.2
cm)
—Baffle panel –
front
2.5 lbs (1.13 kg)18.625 in. 47.3
cm)
21.75in. (55.2 cm
—Baffle panel – rear
Notes:
1
No PFUs or fan trays.
2
Includes four Fan Tray Units and two PFUs.
3
Depth and weight with cable management tray installed and closed, and all card slots filled.
4
Includes shipping container, accessory box, and chassis with four Fan Tray Units and two PFUs
5
Width on the pallet forks.
6
Without cable management bracket.
Environmental Specifications
The ASR 5500 is designed for deployment in unattended sites equipped with redundant power systems,
redundant data communications connections, environmental controls (air conditioning, fire suppression),
security devices and controlled access.
Environmental Parameters
The table below lists the environmental parameters (operating and storage) for the ASR 5500 chassis.
ASR 5500 Installation Guide
16
Technical Specifications
Environmental Specifications
