Cisco ASR 5500 Installation Guide

NotesLED StateLED ColorLabel
Card has failed and is offline.ONRedRun/Fail
OFF
—
Active
OFF
—
Redundant
Card Offline
Card is offline.OFF
—
Run/Fail
OFF
—
Active
OFF
—
Redundant
System Indicators
Normal
System is in service.ONGreenSystem Status
There are no failed components.OFF
—
System Service
Failed Components
System is in service.ONGreenSystem Status
There are failed components.ONAmberSystem Service
Service Loss and Failed Components
System is out of service.ONRedSystem Status
There are failed components.ONAmberSystem Service
Service Loss with No Failed Components
System is out of service.ONRedSystem Status
There are no failed components.OFF
—
System Service
Offline or Transitioning
SSC is offline.OFF
—
System Status
OFF
—
System Service
show leds Command
The show leds command displays the current operating state (color) of the status LEDs of all cards in the
system.
ASR 5500 Installation Guide
95
System Power-up
show leds Command
