D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
121
Figure 5-2 IPv4 Route Table window
The fields that can be configured are described below:
Parameter Description
Network Address
Click the radio button and enter the destination network address of the route to be
displayed.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IPv6 Static/Default Route Settings
A static entry of an IPv6 address can be entered into the Switch’s routing table for IPv6 formatted addresses.
To view the following window, click L3 Features > IPv6 Static/Default Route Settings, as show below:
Figure 5-3 IPv6 Static/Default Route Settings window
The fields that can be configured are described below:
Parameter Description
IPv6 Address/Prefix
Length
This field allows the entry of an IPv6 address to be assigned to the static route. Tick
the Default check box to assign to the default route.
Interface Name
The IP Interface where the static IPv6 route is created.
Nexthop Address
The corresponding IPv6 address for the next hop Gateway address in IPv6 format.
Metric (1-65535)
The metric of the IPv6 interface entered into the table representing the number of
routers between the Switch and the IPv6 address above. Metric values allowed are
between 1 and 65535.
Click the Apply button to accept the changes made.
Click the Delete All button to remove all the entries listed.
