D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
183
Figure 8-19 Initialize Port(s) - MAC-based window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select a range of ports to be configured.
MAC Address
Tick the check box and enter the authenticated MAC address of the client
connected to the corresponding port.
Click the Apply button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings
window before initializing ports. Information in this window cannot be viewed before enabling
the authentication mode for either Port-based or MAC-based.
Reauthenticate Port(s)
This window is used to re-authenticate port(s).
To view this window, click Security > 802.1X > Reauthenticate Port(s) as shown below:
If Port-based is selected in the Authentication Mode drop-down menu in 802.1X Global Settings window, the
following window appears.
Figure 8-20 Reauthenticate Port(s) - Port-based window
If MAC-based is selected in the Authentication Mode drop-down menu in 802.1X Global Settings window, the
following window appears.
Figure 8-21 Reauthentiate Port(s) - MAC-based window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select a range of ports to be configured.
MAC Address
Tick the check box and enter the authenticated MAC address of the client
connected to the corresponding port.
Click the Apply button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings
window before initializing ports. Information in this window cannot be viewed before enabling
the authentication mode for either Port-based or MAC-based.
