D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
85
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
IGMP Snooping Rate Limit Settings
On this page the user can configure the IGMP snooping rate limit parameters.
To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping
Rate Limit Settings, as show below:
Figure 4-39 IGMP Snooping Rate Limit Settings window
The fields that can be configured are described below:
Parameter Description
Port List
Click the radio button and enter the port list used for this configuration.
VID List
Click the radio button and enter the VID list used for this configuration.
Rate Limit (1-1000) Enter the IGMP snooping rate limit used. Tick the No Limit check box to ignore the rate
limit.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IGMP Snooping Static Group Settings
Users can view the Switch’s IGMP Snooping Group Table. IGMP Snooping allows the Switch to read the Multicast
Group IP address and the corresponding MAC address from IGMP packets that pass through the Switch.
To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping
Static Group Settings, as show below:
Figure 4-40 IGMP Snooping Static Group Settings window
The fields that can be configured are described below:
