D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
274
Figure 12-8 Upload Firmware – FTP window
The fields that can be configured are described below:
Parameter Description
FTP Server IP
Enter the FTP Server IP Address used.
User Name
Enter the appropriate Username used.
Password
Enter the appropriate Password used.
TCP Port (1-65535)
Enter the TCP Port number used.
Destination File
Enter the file name that will be stored in the FTP server, e.g. runtime.had.
Source File
Enter the location of the Source File, e.g. C:/runtime.had.
Click Upload to initiate the upload.
Download Configuration
The following window is used to download the configuration file for the Switch.
Download Configuration From TFTP
This window is used to download the configuration file from a TFTP Server to the Switch and updates the switch.
Figure 12-9 Download Configuration – TFTP window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address used.
IPv4
Click the radio button to enter the TFTP server IP address used.
Source File
Enter the file name for the TFTP server to download, e.g. config.cfg.
Destination File
Enter the file name that will be stored in the flash of the Switch, e.g. C:/config.cfg.
Click Download to initiate the download.
