D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
124
Figure 6-2 Default Priority Settings window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select the starting and ending ports to use.
Priority
Use the drop-down menu to select a value from 0 to 7.
Click the Apply button to accept the changes made.
802.1p User Priority Settings
The Switch allows the assignment of a class of service to each of the 802.1p priorities.
To view the following window, click QoS > 802.1p Settings > 802.1p User Priority Settings, as show below:
Figure 6-3 802.1p User Priority Settings window
Once a priority has been assigned to the port groups on the Switch, then a Class may be assigned to each of the
eight levels of 802.1p priorities using the drop-down menus on this window. User priority mapping is not only for the
default priority configured in the last page, but also for all the incoming tagged packets with 802.1p tag.
