xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
199
Figure 8-39 Port Security Port-VLAN Settings window
The fields that can be configured are described below:
Parameter Description
VLAN Name
Click the button and enter the name of the VLAN that the port security settings will be
displayed for.
VID List
Click the button and enter VLAN IDs that the port security settings will be displayed
for.
Max Learning
Address (0-3328)
Specify the maximum value of port security entries that can be learned on this port.
Tick the No Limit check box to have unlimited number of port security entries that
can be learned by the system.
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
Port Security VLAN Settings
Users can configure the maximum number of port-security entries that can be learned on a specific VLAN.
To view this window, click Security > Port Security > Port Security VLAN Settings as shown below:
Figure 8-40 Port Security VLAN Settings window
The fields that can be configured are described below:
Parameter Description
VLAN Name
Enter the VLAN Name.
VID List
Specify a list of the VLAN be VLAN ID.
Max Learning
Address (0-3328)
Specify the maximum number of port-security entries that can be learned by this
VLAN. Tick the No Limit check box to have unlimited number of port security entries
that can be learned by the VLAN.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
