D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
278
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address used.
IPv4
Click the radio button to enter the TFTP server IP address used.
Destination File
Enter the file name that will be stored in the TFTP server, e.g. log.log.
Log Type Select the type of log to be transferred. Selecting the Common Log option here will
upload the common log entries. Selecting the Attack Log option here will upload the log
concerning attacks.
Click Upload to initiate the upload.
Upload Log To FTP
This window is used to upload the log file from the Switch to a FTP Server.
Figure 12-16 Upload Log – FTP window
The fields that can be configured are described below:
Parameter Description
FTP Server IP
Enter the FTP Server IP Address used.
User Name
Enter the appropriate Username used.
Password
Enter the appropriate Password used.
TCP Port
Enter the TCP Port number used.
Destination File
Enter the file name that will be stored in the FTP server, e.g. log.log.
Log Type
Select the type of log to be transferred. Selecting the Common Log option here will
upload the common log entries. Selecting the Attack Log option here will upload the log
concerning attacks.
Click Upload to initiate the upload.
Upload Log To HTTP
This window is used to upload the log file from the Switch to a computer.
