xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
4
Web Pages
When connecting to the management mode of the Switch with a web browser, a login screen is displayed. Enter a user name and
password to access the Switch's management mode.
Below is a list of the main folders available in the Web interface:
Administration – Contains the following folders and windows: IP Address, Interface Settings, Stacking, Port Configuration, User
Accounts, Password Encryption, Port Mirroring, System Log, System Severity Settings, SNTP Settings, MAC Notification
Settings, TFTP Services, Multiple Image Services, Ping Test, IPv6 Neighbor, Routing Table, Gratuitous ARP Settings, Static
ARP Settings, DHCP Auto Configuration, DHCP/BOOTP Relay, DHCP Server, DHCP Server Screening, L2PT Tunneling
Settings, RSPAN, SNMP Manager, PoE, sFlow, IP Multicast VLAN Replication, and Single IP Management Settings.
L2 Features – Contains the following folders and windows: VLAN, Trunking, IGMP Snooping, MLD Snooping, Loopback
Detection Global Settings, Spanning Tree, Forwarding & Filtering, LLDP, and QinQ.
QoS – Contains the following folders and windows: Bandwidth Control, QoS Scheduling Mechanism, QoS Output Scheduling,
802.1p Default Priority, and 802.1p User Priority.
ACL – Contains the following following folders and windows: Time Range, Access Profile Table, ACL Flow Meter and CPU
Interface Filtering.
Security – Contains the following folders and windows: Authorization Network State Settings, Traffic Control, Port Security, IP-
MAC-Port Binding, 802.1X, Web Authentication, Trust Host, Access Authentication Control, MAC Based Access Control,
Safeguard Engine, Traffic Segmentation, SSL, SSH, Multiple Authentication, and JWAC.
Monitoring – Contains the following folders and windows: Device Status, Module Information, CPU Utilization, Port Utilization,
Packets, Errors, Packet Size, Browse Router Port, Browse MLD Router Port, VLAN Status, VLAN Status Port, Port Access
Control, MAC Address Table, IGMP Snooping Group, MLD Snooping Group, Switch Logs, Browse ARP Table, Session Table,
IP Forwarding Table, Browse Routing Table and MAC Based Access Control Authentication Status.
Save Services – Contains the following folders and windows: Save Changes, Configure Information, and Current Configuration
Settings.
Reset, Reboot System and Logout window links are displayed in the main directory.
NOTE: Be sure to configure the user name and password in the User
Accounts window before connecting the Switch to the greater network.
