xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
294
Port Utilization
This window displays the percentage of the total available bandwidth being used on the port.
To view this window, click Monitoring > Port Utilization, as shown below:
Figure 7 - 6 Port Utilization window
To select a port to view these statistics for, first select the Switch in the switch stack by using the Unit drop-down menu and then
select the port by using the Port drop-down menu. The user may also use the real-time graphic of the Switch and/or switch stack at
the top of the web page by simply clicking on a port.
Change the view parameters as follows:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value
is 200.
