xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
293
CPU Utilization
This window displays the percentage of the CPU being used, expressed as an integer percentage and calculated as a simple
average by time interval.
To view this window, click Monitoring > CPU Utilization, as shown below:
Figure 7 - 5 CPU Utilization graph
To view the CPU utilization by port, use the real-time graphic of the Switch and/or switch stack at the top of the web page by
simply clicking on a port. Click Apply to implement the configured settings. The window will automatically refresh with new
updated statistics.
Change the view parameters as follows:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
