106 Configuration: Disk Groups and Virtual Disks
5
In
Advanced virtual disk parameters
, you can select:
Use recommended settings
.
Customize settings
.
6
Click
Next
.
7
In the
Customize Advanced Virtual Disk Parameters
window, select the
appropriate
Virtual Disk I/O characteristics
type. You can select:
File system (typical)
Database
•Multimedia
•Custom
NOTE: If you select Custom, you must select an appropriate segment size.
8
Select the appropriate
Preferred RAID controller module ownership
and
click
Next
.
The
Specify Virtual Disk-to-LUN Mapping
window is displayed.
9
In the
Specify Virtual Disk-to-LUN Mapping
window, you can select:
•Default Mapping
The appropriate
Host type
Map later Using Mappings View
.
10
Click
Finish
.
The virtual disks are created.
Changing the Virtual Disk Modification Priority
You can specify the modification priority setting for a single virtual disk or
multiple virtual disks on a storage array.
Guidelines to change the modification priority of a virtual disk:
If more than one virtual disk is selected, the modification priority defaults
to the lowest priority. The current priority is shown only if a single virtual
disk is selected.
Changing the modification priority by using this option modifies the
priority for the selected virtual disks.
book.book Page 106 Friday, September 23, 2011 2:46 PM
