Dell POWERVAULT MD3600F User Manual

168 Configuration: Premium Feature—Snapshot Virtual Disks
Canceling a Snapshot Rollback
WARNING: Risk of data loss: If you cancel a snapshot rollback in progress, the
base virtual disk may remain in an unusable state and the snapshot virtual disk is
displayed as failed in the MD storage management software. Therefore, do not
cancel a snapshot rollback unless reliable recovery options exist for restoring the
content of the base virtual disk.
1 In the array management window, select the Logical tab.
2 Choose one:
• Select the snapshot virtual disk, and select
Virtual Disk  Snapshot 
Cancel Rollback .
• Right-click the snapshot virtual disk and select
Cancel Rollback .
The
Confirm Cancel Rollback dialog is displayed.
3 To cancel the snapshot rollback, type yes in the confirmation box and
click
OK .
4 Click Yes to cancel the rollback operation.
book.book Page 168 Friday, September 23, 2011 2:46 PM

Dell POWERVAULT MD3600F Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Data transfer rate	8 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	3.6 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	6
Number of storage drives supported	12
Chassis type	-
Product color	Gray
LED indicators	Power, Status
AC input voltage	90-264 V
AC input frequency	47/63 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	600 W
Operating altitude	-16 - 3048 m
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	561 mm
Width	446.3 mm
Height	86.8 mm
Weight	29300 g
