Dell POWERVAULT MD3600F User Manual

256 Management: Installing Array Components
Installing the RAID Controller Module Backup Battery Unit
CAUTION: Many repairs may only be done by a certified service technician. You must
only perform troubleshooting and simple repairs as authorized in your product
documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty.
Read and follow the safety instructions that came with the product.
1 Align the backup battery unit with the slots on the RAID controller module.
2 Slide the backup battery unit toward the connector on the RAID
controller module.
3 Tighten the screw that secures the backup battery unit to the RAID
controller module.
4 Close the RAID controller module. See "Closing the RAID Controller
Module" on page 254.
5 Replace the RAID controller module. See "Installing a RAID Controller
Module" on page 252.
6 Connect all the cables to the array.
7 Turn on the array and the host server.
book.book Page 256 Friday, September 23, 2011 2:46 PM

Dell POWERVAULT MD3600F Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Data transfer rate	8 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	3.6 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	6
Number of storage drives supported	12
Chassis type	-
Product color	Gray
LED indicators	Power, Status
AC input voltage	90-264 V
AC input frequency	47/63 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	600 W
Operating altitude	-16 - 3048 m
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	561 mm
Width	446.3 mm
Height	86.8 mm
Weight	29300 g
