162 Configuration: Premium Feature—Snapshot Virtual Disks
Disabling a Snapshot Virtual Disk
Disable a snapshot virtual disk if:
• You do not need the snapshot now.
• You intend to re-create the snapshot at a later time and want to retain the
associated snapshot repository virtual disk so that you do not need to
create it again.
• You want to maximize storage array performance by stopping copy-on-
write activity to the snapshot repository virtual disk.
NOTE: If you do not intend to re-create the snapshot virtual disk at a later time, in
the Logical pane, select the snapshot virtual disk, and select Virtual DiskDelete
to remove it. The associated snapshot repository virtual disk is also removed. For
more information on removing a snapshot virtual disk, see the PowerVault Modular
Disk Storage Manager online help topics.
NOTE: The SMdevices utility displays the snapshot virtual disk in its output, even
after the snapshot virtual disk is disabled.
To disable a snapshot virtual disk:
1
In the AMW, select the Logical tab, select the snapshot virtual disk, and
select
Virtual Disk  Snapshot  Disable .
2 In the text box, type yes and click OK .
The snapshot virtual disk is disabled. The associated snapshot repository
virtual disk does not change status. The copy-on-write activity to the
snapshot repository virtual disk stops until the snapshot virtual disk is re-
created.
book.book Page 162 Friday, September 23, 2011 2:46 PM

Dell POWERVAULT MD3600F Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Data transfer rate	8 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	3.6 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	6
Number of storage drives supported	12
Chassis type	-
Product color	Gray
LED indicators	Power, Status
AC input voltage	90-264 V
AC input frequency	47/63 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	600 W
Operating altitude	-16 - 3048 m
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	561 mm
Width	446.3 mm
Height	86.8 mm
Weight	29300 g
