Management: Installing Array Components 257
Power Supply/Cooling Fan Module
NOTE: Your storage array includes two integrated, hot-swappable power
supply/cooling fan modules.
The array supports two hot-swappable power supply/cooling fan modules.
While the array can operate temporarily with one module, both the modules
must be present for proper system cooling.
CAUTION: A single power supply/cooling fan module can be removed from a
powered-on array for a maximum period of 5 minutes. Beyond that time, the array
may automatically shut down to prevent damage.
Removing a Power Supply/Cooling Fan Module
CAUTION: Many repairs may only be done by a certified service technician. You must
only perform troubleshooting and simple repairs as authorized in your product
documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty.
Read and follow the safety instructions that came with the product.
NOTE: If you remove a fully functioning power supply/cooling fan module, the fan
speed in the remaining module increases significantly to provide adequate cooling.
The fan speed decreases gradually when a new power supply/cooling fan module
is installed.
1 Turn off the power supply/cooling fan module.
2 Disconnect the power cable from the power source.
3 Remove the straps that secure the power cable and then disconnect the
power cable from the power supply/cooling fan module.
WARNING: The power supply/cooling fan modules are heavy. Use both hands
while removing the module.
4 Press the release tab and pull the power supply out of the chassis.
book.book Page 257 Friday, September 23, 2011 2:46 PM

Dell POWERVAULT MD3600F Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Data transfer rate	8 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	3.6 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	6
Number of storage drives supported	12
Chassis type	-
Product color	Gray
LED indicators	Power, Status
AC input voltage	90-264 V
AC input frequency	47/63 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	600 W
Operating altitude	-16 - 3048 m
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	561 mm
Width	446.3 mm
Height	86.8 mm
Weight	29300 g
