Dell POWERVAULT MD3600F User Manual

Management: Installing Array Components 253
3 Connect all the cables to the RAID controller module. If SFP transceivers
and fiber optic cables were present, reinstall them in the correct ports.
4 If applicable, update the firmware for the RAID controller module. For
information about the latest firmware, see
support.dell.com .
Opening the RAID Controller Module
CAUTION: Many repairs may only be done by a certified service technician. You must
only perform troubleshooting and simple repairs as authorized in your product
documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty.
Read and follow the safety instructions that came with the product.
1 Turn off the array and host server.
2 Disconnect all the power cables connected to the array.
3 Remove the RAID controller module. See "Removing a RAID Controller
Module Blank" on page 249.
4 Remove the screws from the sides of the RAID controller module. See
Figure 16-9.
5 While pressing the indent, slide the cover in the direction of the arrow and
lift it away from the RAID controller module. See Figure 16-9.
book.book Page 253 Friday, September 23, 2011 2:46 PM

Dell POWERVAULT MD3600F Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Data transfer rate	8 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	3.6 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	6
Number of storage drives supported	12
Chassis type	-
Product color	Gray
LED indicators	Power, Status
AC input voltage	90-264 V
AC input frequency	47/63 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	600 W
Operating altitude	-16 - 3048 m
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	561 mm
Width	446.3 mm
Height	86.8 mm
Weight	29300 g
