Troubleshooting: Your Array 301
d
Turn on the server.
e
Check the link status LED. If the link status LED is not green, replace
the cables.
If the problem is not resolved, see "Getting Help" on page 309.
Troubleshooting RAID Controller Modules
CAUTION: Many repairs may only be done by a certified service technician.
You must only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
CAUTION: In the case of non-redundant configurations, it is recommended that
you turn off the host server before turning off the array to prevent loss of data.
• If the array status LED is solid or blinking amber:
a
In the AMW, select the
Summary
tab, and click on
Storage Array
needs attention
. Follow the listed procedures in the Recovery Guru(s)
and wait for up to 5 minutes to check if the LED has turned blue. See
"Recovery Guru" on page 278.
b
If following the recovery guru procedures does not solve the problem,
complete the following procedure to further troubleshoot the array.
c
Turn off the host server as appropriate.
d
Remove the RAID controller module and verify that the pins on
backplane and RAID controller module are not bent. See "Removing a
RAID Controller Module Blank" on page 249.
e
Reinstall the RAID controller module and wait for 30 seconds. See
"Installing a RAID Controller Module" on page 252.
f
Check the RAID controller module status LED.
g
Replace the RAID controller module.
h
Turn on the host server.
If the problem is not resolved, see "Getting Help" on page 309.
book.book Page 301 Friday, September 23, 2011 2:46 PM
