Digi XBee3 802.15.4 User Manual

AT commands SPI interface commands
Digi XBee3® 802.15.4 RF Module User Guide
104
P3 command
Sets or displays the DIO13/UART_DOUT configuration (Micro pin 3/SMT pin 3/TH pin 2).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1 UART DOUT
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
P4 command
Sets or displays the DIO14/UART_DIN configuration (Micro pin 4/SMT pin 4/TH pin 3).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1 UART DIN
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
SPI interface commands
The following commands affect the SPI serial interface on SMT and MMT variants. These commands
are not applicable to the through-hole variant of the XBee3; see D1 through D4 and P2 for through-
hole SPI support.
