Digi XBee3 802.15.4 User Manual

AT commands I/O sampling commands
Digi XBee3® 802.15.4 RF Module User Guide
118
Bit I/O line Device pin
9 DIO9 Micro pin 25/SMT pin 26/TH pin 13
10 DIO10 Micro pin 7/SMT pin 7/TH pin 6
11 DIO11 Micro pin 8/SMT pin 8/TH pin 7
12 DIO12 Micro pin 5/SMT pin 5/TH pin 4
Parameter range
0 - 0x7FFF
Default
0
AV (Analog Voltage Reference)
The analog voltage reference used for A/D sampling.
Parameter range
0 - 2
Parameter Description
0 1.25 V reference
1 2.5 V reference
2 VDDreference
Default
0
IT (Samples before TX)
Sets or displays the number of samples to collect before transmitting data. The maximum number of
samples is dependent on the number of enabled I/O lines and the maximum payload available.
If IT is set to a number too big to fit in the maximum payload, it is reduced such that it will fit. A query
of IT after setting it reports the actual number of samples in a packet.
Parameter range
0x1 - 0xFF
Default
1
IF command
The number of sleep cycles that elapse between periodic I/O samples.
