Digi XBee3 802.15.4 User Manual

OTA firmware upgrade process for 802.15.4 Upgrade End response
Digi XBee3® 802.15.4 RF Module User Guide
180
Frame data fields Offset Example Comments
Data
payload
ZCL frame
header
Frame control 21 0x01
Transaction sequence
number
22 0x30
ZCL payload Command ID 23 0x06 Upgrade End Request
Status 24 0x00 Success = 0x00
Invalid Image = 0x96
Abort = 0x95
Require More Image =
0x99
Manufacturer ID LSB
25
0x1E
MSB
26
0x10
Image type LSB
27
0x00
MSB
28
0x00
Firmware version LSB
29
0x01
30 0x10
31 0x00
MSB
32
0x00
Checksum 38 0x3B
Upgrade End response
If the server receives an Upgrade End request with a SUCCESS status, it generates an Upgrade End
response along with the time at which the device should upgrade to the new image.
Frame data fields Offset Example Comments
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x24
Frame Type 3 0x11
Frame ID 4 0x01
