AT commands I/O settings commands
Digi XBee3® 802.15.4 RF Module User Guide
111
Parameter Description
4 Digital output, low
5 Digital output, high
Default
1
D9 command
Sets or displays the DIO9/ON_SLEEP configuration (Micro pin 25/SMT pin 26/TH pin 13).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
ON/SLEEP indicator
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
P0 command
Sets or displays the DIO10/RSSI/PWM0 configuration (Micro pin 7/SMT pin 7/TH pin 6).
When configured as RSSI PWM output, the device outputs a PWM signal with a duty cycle equivalent to
the dBm of the received packet.
Use RP command to configure the timeout.
When configured as PWM output (2): you can use M0 to explicitly control the PWM0 output. When used
with Analog line passing, PWM0 corresponds with ADC0.
Parameter range
0 - 5
Parameter Description
0 Disabled
1 RSSI PWM output
