Digi XBee3 802.15.4 User Manual

AT commands Sleep settings commands
Digi XBee3® 802.15.4 RF Module User Guide
97
Default
0x7D0 (2 seconds)
DP (Disassociated Cyclic Sleep Period)
Sets or displays the sleep period for cyclic sleeping remotes that are configured for Association but
that are not associated to a Coordinator. For example, if a device is configured to associate and is
configured as a Cyclic Sleep remote, but does not find a Coordinator, it sleeps for DP time before
reattempting association.
Parameter range
1 - 0x15F900 (x 10 ms)
Default
0x3E8 (10 seconds)
SO command
Set or read the sleep options bit field of a device. This command is a bitmask.
You can set or clear any of the available sleep option bits.
Parameter range
0 - 0x103
Bit field:
Bit Setting Meaning Description
0 0 Normal
operations
A device configured for cyclic sleep will poll for data on waking
1 Disable wakeup
poll
A device configured for cyclic sleep will not poll for data on waking
1 0 Normal
operations
A device configured in a sleep mode with ADC/DIO sampling enabled
will automatically perform a sampling on wakeup
1 Suppress
sample on
wakeup
A device configured in a sleep mode with ADC/DIO sampling enabled
will not automatically sample on wakeup
8 0 Normal
operations
A device configured for cyclic sleep will wake only momentarily after
the expiration of SP
1
Always wake
for STtime
A device configured for cyclic sleep will always remain awake for ST
time before returning to sleep
Set all other option bits to 0.
Default
0
