Network commissioning and diagnostics Remote configuration commands
Digi XBee3® 802.15.4 RF Module User Guide
72
Remote configuration commands
When running in API mode, the firmware has provisions to send configuration commands to remote
devices using Remote AT Command Request frame - 0x17. You can use this frame to send commands
to a remote device to read or set command parameters.
CAUTION! It is important to set the short address to 0xFFFE when sending to a long address.
Any other value causes the long address to be ignored. This is particularly problematic in the
case where nodes are set up with default addresses of 0 and the 16-bit address is
erroneously left at 0. In that case, even with a correct long address the remote command
goes out to all devices with the default short address of 0, potentially resulting in harmful
consequences, depending on the command.
Send a remote command
To send a remote command populate the Remote AT Command Request frame (0x17) with:
1. The 64-bit address of the remote device.
2. The correct command options value.
3. The command and parameter data (optional). If (and only if) all nodes in the PAN have unique
short addresses, then remote configuration commands can be sent to 16-bit short addresses
by setting the short address in the API frame for Remote AT commands. In that case, the 64-bit
address is unused and does not matter.
Apply changes on remote devices
Any changes you make to the configuration command registers using AT commands do not take effect
until you apply the changes. For example, if you send the BD command to change the baud rate, the
actual baud rate does not change until you apply the changes. To apply changes:
1. Set the Apply Changes option bit in the Remote AT Command Request frame (0x17).
2. Issue an AC (Apply Changes) command to the remote device.
3. Issue a WR + FR command to the remote device to save changes and reset the device.
Remote command responses
If the remote device receives a Remote AT Command Request (0x17 frame type), the remote sends an
AT Command Response (0x88 frame type) back to the device that sent the remote command. The AT
command response indicates the status of the command (success, or reason for failure), and in the
case of a command query, it includes the parameter value.
The device that sends a remote command will not receive a remote command response frame if the
frame ID in the remote command request is set to 0 , indicating that the request is sent without
acknowledgment.
Node discovery
Node discovery has three variations as shown in the following table:
