Digi XBee3 802.15.4 User Manual

AT commands I/O settings commands
Digi XBee3® 802.15.4 RF Module User Guide
109
Parameter Description
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D3 command
Sets or displays the DIO3/ADC3/TH_SPI_SSEL configuration (Micro pin 28/SMT pin 30/TH pin 17).
Parameter range
SMT/MMT: 0, 2 - 5
TH: 0 - 5
Parameter Description
0 Disabled
1
SPI_SSEL for the through-hole device
N/A for surface-mount device
2 ADC
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D4 command
Sets or displays the DIO4/TH_SPI_MOSI configuration (Micro pin 23/SMT pin 24/TH pin 11).
Parameter range
SMT/MMT: 0, 3 - 5
TH: 0, 1, 3 - 5
Parameter Description
0 Disabled
1
SPI_MOSI for the through-hole device
N/A for the surface-mount and micro device
