Digi XBee3 802.15.4 User Manual

AT commands 802.15.4 Addressing commands
Digi XBee3® 802.15.4 RF Module User Guide
88
Default
0xFFFF
DA (Force Disassociation)
Causes the End Device to immediately disassociate from a Coordinator (if associated) and re-attempt
to associate.
Parameter range
-
Default
-
AI command
Reads the Association status code to monitor association progress.
The following table provides the status codes and their meanings.
Status
code Meaning
0x00 Coordinator successfully started, End device successfully associated, or operating in peer
to peer mode where no association is needed.
0x03 Active Scan found a PAN coordinator, but it isn't currently accepting associations.
0x05
Active Scan found a PAN, but the PAN ID doesn't match the configured PAN ID on the
requesting end device and bit 0 of A1 is not set to allow reassignment of PAN ID.
0x06
Active Scan found a PAN on a channel that does not match the configured channel on the
requesting end device and bit 1 of A1 is not set to allow reassignment of the channel.
0x0C Association request failed to get a response.
0x13 End device is disassociated or is in the process of disassociating.
0xFF Initialization time; no association status has been determined yet.
Parameter range
0 - 0xFF [read-only]
Default
N/A
802.15.4 Addressing commands
The following commands affect the source and destination addressing for the device.
SH command
Displays the upper 32 bits of the unique IEEE 64-bit extended address assigned to the XBee in the
factory.
