Digi XBee3 802.15.4 User Manual

Frame descriptions Receive Packet frame - 0x90
Digi XBee3® 802.15.4 RF Module User Guide
158
Receive Packet frame - 0x90
Description
When a device configured with a standard API Rx Indicator (AO command = 0) receives an RF data
packet, it sends it out the serial interface using this message type.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data fields Offset Description
Frame type 3 0x90
64-bit source address 4-11
The sender's 64-bit address. MSB first, LSB last.
Reserved
12-13 16-bit source address.
Receive options
14
Bit
Interpretation
0 Packet acknowledged
1 Broadcast packet
2 - 5 Reserved
6 - 7 Delivery mode:
b 00 Invalid
b 01 Point-to-multipoint
b 10 Repeater mode
b 11 DigiMesh
Received data
15 - n The RF data the device receives.
Example
In the following example, a device with a 64-bit address of 0x0013A200 40522BAA sends a unicast
data transmission to a remote device with payload RxData. If AO = 0 on the receiving device, it sends
the following frame out its serial interface.
Frame data fields Offset Example
Start delimiter 0 0x7E
