OTA firmware upgrade process for 802.15.4 Create the Image Notify request
Digi XBee3® 802.15.4 RF Module User Guide
169
Create the Image Notify request
The Image Notify Request is an explicit transmit frame (0x11 type) passed into the server with the
following information:
Frame data fields Offset Example Comments
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x21
Frame Type 3 0x11
Frame ID 4 0x01
64-bit destination address MSB 5 0x00
6 0x13
7 0xA2
8 0xFE
9 0x00
10 0x00
11 0x00
LSB
12
0x03
16-bit destination address MSB
13
0x28
LSB
14
0x2F
Source Endpoint 15 0xE8
Destination Endpoint 16 0xE8
Cluster ID MSB
17
0x00
LSB
18
0x19
Profile ID MSB
19
0xC1
LSB
20
0x05
Broadcast radius 21 0x00
Transmit options 22 0x00
