EFI E-35A User Manual

76 Installation and Service Guide
Replacing Parts
Power supply
This section describes how to remove and replace the E-35A power supply. For more information about the power
supply, see “Specifications” on page 116.
To remove the power supply
1 Access and open the E-35A (see page 49).
2 Remove the 24-pin power cable from the motherboard (see page 48).
3 Remove the 4-pin power cable from the motherboard (see page 48).
4 Remove the power cable from the power connector on the HDD (see page 48).
5 Remove the power supply cables from the plastic clips that secure them to the chassis.
6 Remove the four screws that attach the power supply to the chassis (see page 77).
Set the screws aside so that you can replace them later.
Caution:Do not open the power supply for service or troubleshooting. Opening the power supply will void the
warranty.
