82 Installation and Service Guide
Replacing Parts
8 Reassemble the E-35A (see page 82).
9 Connect the external cables that you removed from the E-35A.
10 If you replaced the HDD with a new HDD, install system software (see page 96).
11 Verify the functionality of the E-35A (see page 82).
Restoring and verifying functionality after service
Complete your inspection and service by reassembling and verifying the E-35A.
To reassemble and verify the E-35A
1 Reseat all boards, cables, connectors, and other parts loosened or removed during service.
When routing cables in the E-35A make sure that:
• Covers are securely installed after routing cables.
• Cables are not looped around internal circuit boards, or components (such as capacitors and resistors).
• Cable routing does not interfere with the operation of internal components.
• Cables do not lie on or against any internal heating element.
• Cables do not interfere with removing or replacing components.
• Cables do not interfere with opening or closing E-35A panels.
• Cables are not tangled.
• Cable slack is secured with tie wraps.
2 Restore the system to the upright position.
3 Replace any panels that you removed earlier, as described in “Opening the E-35A” on page 49.
4 Reinstall the E-35A in the furniture, as described in “To replace the E-35A in the furniture” on page 119.
5 If you installed a new hard disk drive, install system software (see page 96).
Replacement hard disk drives are not shipped with pre-installed system software.
6 If you replaced the motherboard with a new motherboard, make sure that the new motherboard solves the
problem that you are troubleshooting (see page 103), and then transfer options to the new motherboard (see
page 66).
7 Make sure to configure the date and time in Setup (see page 73).
8 Before you leave the customer site, verify the E-35A operation.
Warning: Do not lift the E-35A without assistance. Follow standard ESD “Precautions” on page 10 when
handling internal components.
