99 Installation and Service Guide
Installing System Software
Prepare the USB flash drive
Using Fiery Installer Builder you can prepare a USB flash drive as a bootable device and then load the system software
files on to the USB flash drive. The approximate time required to prepare the USB flash drive is 25 to 30 minutes. Using
the prepared USB flash drive, you can install the system software to an existing HDD on the E-35A.
To prepare the USB flash drive
1 Attach the USB flash drive to an USB 3.0 port on your computer.
Note: Due to the file system restriction, the maximum size of the USB flash drive you can use is 32GB. The
minimum size required is 16GB.
2 Double-click the Fiery Installer Builder icon on the desktop. You can also click Start > EFI > Fiery Installer Builder.
3 At the Downloaded window, select Color Controller E-35A 1.0.
4 From the Prepare action pull-down menu, select Prepare USB Flash drive.
5 Click Next.
6 At the Select Flash drive window, click the USB flash drive that you attached to the computer, and click Next.
If more than one USB devices are displayed, make sure to select the USB flash drive that you attached for loading
the system software.
A warning message “This USB flash drive will be formatted and all the data in this USB flash drive will be lost.”
appears. Click Next to format the USB flash drive and proceed.
Note: It will take approximately 30 to 40 minutes to format the USB flash drive and load the files on to the drive.
Do not interrupt the operation.
7 Once the preparation is done, safely disconnect the USB flash drive from the computer.
You can use this USB flash drive as a source for system software installation.
Install the system software using the prepared USB flash drive
You can install the system software using the prepared USB flash drive.
To install the system software
1 Remove all the USB devices that are attached to the E-35A.
2 Shut down the E-35A (see page 42).
3 Disconnect all external cables from the E-35A, except the power cable.
Note: Be sure to leave the power cable connected between the E-35A and the power outlet.
4 Attach the prepared USB flash drive to one of the USB 3.0 ports on the E-35A.
Important: All the data on the USB flash drive will be lost when you format the USB flash drive. Make sure that
no valuable data is stored on the device.
