CONTROLS, INSTRUMENTS
AND.
OPERATION-··
--
1.
Suspension adjuster
2. Weight indicator
OPERATOR'S SEAT
Two· types
of
seat
are
available,
each
having a
comprehensive range
of
adjusunents. Before op-
erating the tractor,
it
is important
to
adjust the seat
to the most comfonable position. Ref er
to
Figures
1 or 2
io identify the seat fitted
to
your tractor.
NOTE:
Do
not
use
solvents·
to
clean
the
seat.
Use
warm water with a little detergent
added.
Seat - Figure 1
While sitting in the seat, adjust
the
suspension by
cranking the ratchet handle
from
side
to
side.
The ratchet is reversible. With the plus (+)sign on
the handle uppermost,
as
shown, cranking
the
handle will increase suspension stiffness
to
give a
finner ride. Pull the handle out and rotate half a
tum until the minus (-) sign is uppermost. The
ratchet action
is
now
reversed
and
the seal suspen-
sion will become softer
as
the handle
is
cranked.
The optimum
setting
will
be achieved when, with
the operator seated,
the
weight indicator on
the
left-hand side
of
the
scat indicates
the
approx.i-
·
2
2.
Seat
1.
Suspension adjuster
2.
Weight indicator
3.
Height adjustment knobs
4.
Seat travel adjuster
male size
of
the operator. This is denoted by
two
symbols indicating a large and a small man with,
of
course,
an
infinite number
of
positions in be-
tween
Fore
and
aft scat travel is effected after loosening
the
bolts securing the seal base
lo
the tractor.
Seat - Figure 2
To
achieve the optimum suspension setting, tum
the
knob on the back
of
the seat until the weight
indicator registers your approximate weighL
To adjust
the
scat height, loosen the two knobs lo-
cated
low
down on either side
of
the scat frame
and
lift
the
seat
to
the required
height
Tighten the
bolts.
Lift the travel adjustment lever
and
slide the seat
backwards
or
forwards,
a.~
required.
The
scat wil1
lock
in position when the lever is released
..
On
units not equipped with deluxe remote control
valves. f urthcr travel
adj_ustmcnt
is possible after
loosening
the
two bolts that secure the scat base
to
the
tractor.
