6.6 Messages
6-21
6.6 Messages
Following describes the messages which appear on the control unit and NBDP terminal unit.
6.6.1 Message on control unit
LOAD CONFIG DATA FROM TRX UNIT
The data is loaded from T-CPU to C-CPU at power-on. This is not an error message.
OVEN COLD Tx not ready: WAIT
The oven needs to heat for stabilizing 18 MHz REF oscillator output.
Warning: EPFS error
Position and time data are not received from EPFS (Electronic Position Fixing System) for
60 seconds.
Check EPFS for connection. The receivable NMEA sentences are GGA, RMC, GLL and
ZDA. NMEA version is 2.0 or above.
Warning: Update position
Position and time data are not updated for the time set at POSITION OLDER menu. Update
the position.
Tx pow reduced Natural tune
The antenna current exceeds 10 A for more than 5 seconds. The output power is
automatically reduced with this message.
Change the antenna impedance. Typically, the antenna is changed in length.
To Next Page
