7.1 Output power
7-1
7.1 Output power
7.1.1 Power Data
Output power is adjusted by setting power data for specific frequency range and
emission mode as shown in Table 7.1.1. High, middle and low powers are adjusted. The
output power of each user channel is preset at the registration of the user channel. The
ITU channel also uses the power data in Table 7.1.1.
Table 7.1.1 Power data setting list
HI Power MID Power LOW Power
BAND
SSB (LSB) TLX (DSC) SSB (LSB) TLX (DSC) SSB (LSB) TLX (DSC)
1.6-1.9999
! ! ! ! ! !
2.0-2.9999
! ! ! ! ! !
3.0-4.9999
! ! ! ! ! !
4.0-5.9999
! ! ! ! ! !
6.0-7.9999
! ! ! ! ! !
8.0-11.9999
! ! ! ! ! !
12.0-15.9999
! ! ! ! ! !
16.0-17.9999
! ! ! ! ! !
18.0-21.9999
! ! ! ! ! !
22.0-24.9999
! ! ! ! ! !
25.0-26.9999
! ! ! ! ! !
27.0-27.4999
! ! ! ! ! !
ITU Channel
Same power data as band
User Channel (RT setup – USER CH Entry: Max. 255 CH)
0- 25 BAND Each channel
!
: individual setting
The default setting of power data is listed in Table 7.1.2.
Table 7.1.2 Default setting of power data
Default
FS-1570T output
(J3E 4 MHz)
FS-2570T output
(J3E 4MHz)
Setting range
HIGH 240 150 W 250 W 0 to 255
MID
210(FS-1570)
180(FS-2570)
120 W 125 W 0 to 255
LOW
195 (FS-1570)
160 (FS-2570)
90 W 85 W 0 to 255
TUNE 90 15 W 18 W 0 to 140
Chapter 7. Adjustment and Measurement
