1.8 Power Status Monitor, PSM-01
1-8
1.8 Power Status Monitor, PSM-01
The power status monitor, PSM-01 is optionally available. The unit generates aural and
visual alarms when the ship’s supply is switched from the ship’s mains to the reserve source.
The unit is installed at the place where the ship is normally navigated.
Fig.1.8.1 Connection of PMS-01
1.9 Using NBDP
When using the NBDP, taking into account the followings.
1) NBDP frequency is set on the NBDP terminal but not on the RT.
2) The NBDP can be used only when “Occupied NBDP” appears on the RT display.
IB-583 brightness adjustment
Press [F6] while holding [Alt] to decrease the brightness by 8 levels. To increase the
brightness, press [F7] while holding [Alt].
